TKU Thermal Imaging Scope
| Parameter classification | Specific parameters | Parameter Value |
| Detector parameters | Detector Type | Uncooled Vanadium Oxide (VOx) Microbolometer |
| Resolution | 640 × 512 pixels | |
| Pixel size | 12 μm | |
| Spectral response range | 8 - 14 μm | |
| Thermal sensitivity (NETD) | < 35 mK @ F1.0 | |
| Refresh rate | 50 Hz | |
| Optical parameters | Objective | 50mm F1.0 |
| Field of view | 12.4° × 9.9° | |
| Magnification | Basic 4× (digital zoom up to 16×) | |
| Eyepiece diopter adjustment | -5 ~ +5 diopters | |
| Focus range | 5 m to infinity | |
| Display parameters | Display Type | 1024 × 768 OLED micro display |
| Color Mode | White hot, black hot, red hot, rainbow, iron red, hot iron red | |
| Aim for the baseline | Multiple optional aiming baseline styles | |
| Detection performance | Detection distance (1.7m × 0.5m humanoid target) | 2200 m |
| Identification distance (1.7m × 0.5m humanoid target) | 600 m | |
| Interface and Function | Data Interface | USB Type-C, Wi-Fi, Bluetooth |
| Video Output | Support output via USB-C | |
| Built-in storage | 32 GB | |
| GPS | Built-in GPS/GLONASS receiver | |
| Physical parameters | Dimensions (length x width x height) | 320 × 86 × 68 mm |
| weight | 850 g (including battery) | |
| Mounting interface | Standard Picatinny/Weaver Rails | |
| Shell material | Aviation grade aluminum alloy | |
| Environmental parameters | Operating temperature | -40°C ~ +60°C |
| Storage temperature | -45°C ~ +65°C | |
| Waterproof grade | IP67 (submersible in water to a depth of 1 meter for 30 minutes) | |
| Shock resistance | Withstands .375 H&H caliber recoil | |
| Power parameters | Battery Type | Removable lithium-ion battery pack |
| Battery capacity | 6800 mAh | |
| Working hours | 8 hours (standard mode) | |
| External power supply | Support USB-C power supply |
